LED Gas Station Light – ST-GS-C
Certification CE, RoHS
Warranty 5 years
Lamp body Aluminum
Light source LUMILEDS
Luminaire’s Efficiency 130Lm/W
Driver Meanwell
Product Description
Features
| Product | Led gas station light (ST-GS-C) |
| Certification | CE, RoHS |
| Warranty | 5 years |
| Lamp body | Aluminum |
| Light source | LUMILEDS |
| Luminaire’s Efficiency | 130Lm/W |
| Driver | Meanwell |
| Installation method | Ceiling mount |
| Application | Gas station, parking lot etc |
Parameter
| Model | Power | Input voltage | Light Source |
Luminous Flux |
Luminaire’s Efficiency |
Product size | N.W | G.W | Packing (mm) |
|---|---|---|---|---|---|---|---|---|---|
| ST-GS-C-40W | 40W | 100-277VAC 50-60HZ |
LUMILEDS | 5200Lm | 130Lm/W | L327 * W380 * H110mm | 4.8kg | 5.8kg | L370 * W450 * H140mm |
| ST-GS-C-60W | 60W | 100-277VAC 50-60HZ |
LUMILEDS | 7800Lm | 130Lm/W | L327 * W380 * H110mm | 4.8kg | 5.8kg | L370 * W450 * H140mm |
| ST-GS-C-80W | 80W | 100-277VAC 50-60HZ |
LUMILEDS | 10400Lm | 130Lm/W | L327 * W380 * H110mm | 4.8kg | 5.8kg | L370 * W450 * H140mm |
| ST-GS-C-90W | 90W | 100-277VAC 50-60HZ |
LUMILEDS | 11700Lm | 130Lm/W | L430 * W390 * H110mm | 5.8kg | 6.8kg | L470 * W450 * H140mm |
| ST-GS-C-100W | 100W | 100-277VAC 50-60HZ |
LUMILEDS | 13000Lm | 130Lm/W | L430 * W390 * H110mm | 5.8kg | 6.8kg | L470 * W450 * H140mm |
| ST-GS-C-120W | 120W | 100-277VAC 50-60HZ |
LUMILEDS | 15600Lm | 130Lm/W | L430 * W390 * H110mm | 5.8kg | 6.8kg | L470 * W450 * H140mm |
| ST-GS-C-150W | 150W | 100-277VAC 50-60HZ |
LUMILEDS | 19500Lm | 130Lm/W | L517 * W380 * H110mm | 7.5kg | 8.9kg | L560 * W450 * H140mm |
| ST-GS-C-180W | 180W | 100-277VAC 50-60HZ |
LUMILEDS | 23400Lm | 130Lm/W | L517 * W380 * H110mm | 7.5kg | 8.9kg | L560 * W450 * H140mm |
| ST-GS-C-200W | 200W | 100-277VAC 50-60HZ |
LUMILEDS | 26000Lm | 130Lm/W | L517 * W380 * H110mm | 7.5kg | 8.9kg | L560 * W450 * H140mm |
Downloads
DS851LR4-1 Data Sheet
2.52 MB
DS851LR4-1 Data Sheet
2.52 MB
DS851LR4-1 Data Sheet
2.52 MB
