Features
| Product | Led garden light (ST-T91/-C) |
| Certification | TUV ENEC, CB, CE, IK10, IP66, LM79, LM80 |
| Warranty | 5 years |
| Lamp body | Die-cast aluminum |
| Light source | Nichia Led |
| Luminaire’s Efficiency | 120~130Lm/W |
| Optical | Anodized aluminium reflector and PC diffuser |
| Gear plate | Galvanized steel plate |
| Finishing | Surface anti-ageing electrostatic spray processing Super resistance to corrosion |
| Installation height | 4 – 6M |
| Fixing | Ø38mm tube hanging |
Parameter
| Model | Power | Input voltage | Light Source | Luminous Flux | Luminaire’s Efficiency | Product size | N.W | G.W | Packing(mm) |
| ST-T91-30W ST-91-C-30W | 30W | 100-277VAC 50-60HZ | Nichia Led | 3903Lm | 120-130Lm/W | Ø560 * H411mm Ø590 * H670mm | 5.8kg | 6.8kg | L580 * W580 * H350mm L590 * W590 * H670mm |
| ST-T91-40W ST-91-C-40W | 40W | 100-277VAC 50-60HZ | Nichia Led | 5255Lm | 120-130Lm/W | Ø560 * H411mm Ø590 * H670mm | 5.8kg | 6.8kg | L580 * W580 * H350mm L590 * W590 * H670mm |
| ST-T91-60W ST-91-C-60W | 60W | 100-277VAC 50-60HZ | Nichia Led | 7090Lm | 120-130Lm/W | Ø560 * H411mm Ø590 * H670mm | 5.8kg | 6.8kg | L580 * W580 * H350mm L590 * W590 * H670mm |
| ST-T91-80W ST-91-C-80W | 80W | 100-277VAC 50-60HZ | Nichia Led | 9556Lm | 120-130Lm/W | Ø560 * H411mm Ø590 * H670mm | 6.2kg | 7.2kg | L580 * W580 * H350mm L590 * W590 * H670mm |
| ST-T91-90W ST-91-C-90W | 90W | 100-277VAC 50-60HZ | Nichia Led | 10935Lm | 120-130Lm/W | Ø560 * H411mm Ø590 * H670mm | 6.5kg | 7.5kg | L580 * W580 * H350mm L590 * W590 * H670mm |
